Description

The JC-26X introduces rear suspension into the model range. Along with this there are a wide range of choices within the 3 categories of across the 27 speed, 30 speed,Deore. Stadardizard across all three models you’ll find an aircraft-grade aluminum frame, Parking levers, and Michelin tires, plus the FRP (Fiber Reinforced Plastic) cushion mesh seat with a headrest. The Chrome Moly fork means extra strength but not extra weight. Chrome Moly is a high-quality steel that will take the punishment that the roads will dish out in the 1000s and 1000s of miles ahead.

The 27 Speed is characterized by the 9s Shimano cassette and the Tektro Mechanical Disc Brakes. The higher end of the chainring delivers a 50/11 for sporty descents and rip roaring tearaways along the flats. The lower end gives you a 30/34 combination that would get you up K2 in the Himalayas (and the rear rack gives you plenty of oxygen bottle storage capacity…).

The 30 Speed gives you the key components of Shimano’s fantastic Tiagra 10 speed groupset along with REVER mechanical disc brakes. REVER have done a great job with the design here. There’s an inboard pad-adjustment knob that allows fine tuning the distance between the rotors and the pads. Add the very nifty Tri-Align caliper positioning system to this (aligns the pads parallel to the rotor in around a jiffy), and you have a powerful and durable braking system that will serve you well for a long time.

Finally, excellent function of Deore Goupset with Deore rear derailleur anf Deore11-36t cassette. Coupled with the 30t chain ring (smallest of the triple crank) means serious climbing power. It’s not about speed, but versatility; and you’ll climb almost anything with that combo.

Choose Your Color

6-colors

Specifications

ItemDescription
Main FrameAluminum 6061
Rear forkCr-Mo
SeatFRP w/mesh cushion . headrest
Handle barAluminum handle bar / steering
ShiftersMicroshift bar end shifter M19
LeversParking Lever
Front DerailleurMicroshift FD-M462B
Rear DerailleurMicroshift RD-M6195L
CranksetFSA 50/34t 165L
CassetteMicroshift CS-H093 11-32T
WheelsetF/mono 32H
R/chosen A5017 32H
Tires20″ / 26″ x 1.5
BrakesTekro MDC-510 flat mount
PedalClipless
AccessoriesFenders, rear rack, flag, mirror
MSRPUS$2,180


ItemDescription
Main FrameAluminum 6061
Rear forkCr-Mo
SeatFRP w/mesh cushion . headrest
Handle barAluminum handle bar / steering
ShiftersMicroshift bar end shifter M10
LeversParking Lever
Front DerailleurMicroshift FD-M612B
Rear DerailleurMicroshift RD-M61L
CranksetFSA 46/30t 170L
CassetteMicroshift CS-H100 11-32T
WheelsetF/mono 32H
R/chosen A5017 32H
Tires20″ / 26″ x 1.5
BrakesREVER MCX02 flat mount
PedalClipless
AccessoriesFenders, rear rack, flag, mirror
MSRPUS$2,380


ItemDescription
Main FrameAluminum 6061
Rear forkCr-Mo
SeatFRP w/mesh cushion . headrest
Handle barAluminum handle bar / steering
ShiftersMicroshift bar end shifter M11
LeversParking Lever
Front DerailleurMicroshift FD-M622B
Rear DerailleurMicroshift RD-M665L
CranksetFSA 46/30t 170L
CassetteMicroshift CS-H110 11-32T
WheelsetF/mono 32H
R/chosen A5017 32H
Tires20″ / 26″ x 1.5
BrakesREVER MCX02 flat mount
PedalClipless
AccessoriesFenders, rear rack, flag, mirror
MSRPUS$2,555


Bottom Bracket HeightSeat HeightSeat angle-from HorizontalTop of seatTop of Headrest
42.5cm23cm36-39 degrees86cm103cm
Wheel baseAverage weight/kgRider’s weight limitedX-seam/inch
112cm20kgs120kgsM : 33″~40″
L : 39.5″ ~ 48″


*The components may change due to  the availability.
